Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Texas Instruments |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Standard (General Purpose) |
| Number of Elements | 1 |
| Output Type | Open-Drain, Push-Pull |
| Voltage – Supply, Single/Dual (±) | 2.7V ~ 5.5V, 3V ~ 27V |
| Voltage – Input Offset (Max) | – |
| Current – Input Bias (Max) | 0.025µA @ 4V |
| Current – Output (Typ) | 4mA |
| Current – Quiescent (Max) | 2.2mA, 3.6mA |
| CMRR, PSRR (Typ) | – |
| Propagation Delay (Max) | 320ns |
| Hysteresis | 25mV |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 8-SOIC (0.295″, 7.50mm Width) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SOIC |
