Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Tensility International Corp |
| Series | PPL7 |
| Packaging | Bulk |
| Part Status | Active |
| Connector Type | Plug, Male Pins |
| Number of Positions | 6 |
| Shell Size – Insert | 0 |
| Shell Size, MIL | – |
| Mounting Type | Free Hanging (In-Line) |
| Mounting Feature | – |
| Termination | Solder Cup |
| Fastening Type | Push-Pull |
| Orientation | 0 |
| Primary Material | Metal |
| Shell Material | Brass |
| Shell Finish | Nickel |
| Contact Finish – Mating | Gold |
| Color | Silver |
| Ingress Protection | IP50 – Dust Protected |
| Material Flammability Rating | UL94 V-0 |
| Features | Backshell |
| Shielding | Shielded |
| Current Rating (Amps) | 2.5A |
| Voltage Rating | 300V |
| Cable Opening | 0.205″ (5.20mm) |
| Operating Temperature | -55°C ~ 220°C |
| Backshell Material, Plating | Brass, Nickel |
| Contact Material | Brass |
| Contact Finish Thickness – Mating | 8.00µin (0.203µm) |
| Insert Material | Polyphenylene Sulfide (PPS) |
| Applications | – |
| Base Product Number | 51-00022 |
