Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Series | HCR 150 |
| Packaging | Bulk |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 130 A |
| Switching Voltage | 12VDC – Nom |
| Must Operate Voltage | 7.2 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 25 ms |
| Release Time | 8 ms |
| Features | – |
| Mounting Type | Chassis Mount |
| Termination Style | Screw Terminal |
| Operating Temperature | -40°C ~ 125°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Coil Power | 3.9W |
| Coil Resistance | 37 Ohms |
| Base Product Number | 1393315 |
