Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TE Connectivity Aerospace, Defense and Marine |
| Series | K81A, KILOVAC |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 26.5VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 10 A |
| Switching Voltage | 10000VDC – Nom |
| Load – Max Switching | – |
| Coil Current | 91.4 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Stud |
| Seal Rating | Sealed – Fully |
| Coil Insulation | – |
| Must Operate Voltage | 16 VDC |
| Must Release Voltage | 1 VDC |
| Operate Time | 10 ms |
| Release Time | 10 ms |
| Operating Temperature | -55°C ~ 85°C |
| Contact Material | – |
| Approval Agency | – |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 290 Ohms |
| Base Product Number | K81AB |
