Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | MAD, CII |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 26.5VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 115VAC, 28VDC – Max |
| Load – Max Switching | 115VA, 28W |
| Coil Current | 17 mA |
| Coil Type | Non Latching |
| Features | Diode |
| Termination Style | PC Pin |
| Seal Rating | Sealed – Hermetically |
| Coil Insulation | – |
| Must Operate Voltage | 14.2 VDC |
| Must Release Voltage | 1.37 VDC |
| Operate Time | 2 ms |
| Release Time | 4 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Approval Agency | – |
| Relay Type | General Purpose |
| Grade | Military |
| Qualification | MIL-R-39016/15 |
| Coil Resistance | 1.56 kOhms |
| Base Product Number | JMAWD |
