Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | TE Connectivity Aerospace, Defense and Marine |
| Series | FCAC-150, CII |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 28VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Contact Rating (Current) | 50 A |
| Switching Voltage | – |
| Load – Max Switching | – |
| Coil Current | 96.6 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Stud |
| Seal Rating | Sealed – Hermetically |
| Coil Insulation | – |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 1.5 VDC |
| Operate Time | 15 ms |
| Release Time | 15 ms |
| Operating Temperature | -70°C ~ 125°C |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Approval Agency | – |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 290 Ohms |
| Base Product Number | 1617798 |
