Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | 3SBC, CII |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 18VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 115VAC, 28VDC – Max |
| Load – Max Switching | 230VA, 56W |
| Coil Current | 27.7 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | PC Pin |
| Seal Rating | Sealed – Hermetically |
| Coil Insulation | – |
| Must Operate Voltage | 9.5 VDC |
| Must Release Voltage | 1 VDC |
| Operate Time | 4 ms |
| Release Time | 4 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | – |
| Approval Agency | – |
| Relay Type | General Purpose |
| Grade | Military |
| Qualification | MIL-R-39016/13 |
| Coil Resistance | 650 Ohms |
| Base Product Number | 3SBC2 |
