Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Sensata-Gigavac Clean Energy |
| Series | PNC113 |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NC (DB) (1 Form Y) |
| Contact Rating (Current) | 30 A |
| Switching Voltage | 1500VDC – Max |
| Features | Sealed – Hermetically |
| Termination Style | Stud |
| Operating Temperature | -40°C ~ 65°C |
| Must Operate Voltage | 7.5 VDC |
| Must Release Voltage | 0.2 VDC |
| Contact Material | – |
| Operate Time | 25 ms |
| Release Time | 8 ms |
| Coil Current | 170 mA |
| Coil Power | 2.04W |
| Coil Resistance | 70Ohms |
