Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Schneider Electric |
| Series | Harmony |
| Packaging | Box |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 30 A |
| Switching Voltage | 277VAC, 28VDC – Max |
| Load – Max Switching | 8310VA, 840W |
| Coil Current | 36.4 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Quick Connect – 0.187″/0.250″ |
| Seal Rating | Sealed – Fully |
| Coil Insulation | – |
| Must Operate Voltage | 19.2 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 20 ms |
| Release Time | 10 ms |
| Operating Temperature | -40°C ~ 40°C |
| Contact Material | Silver Alloy |
| Approval Agency | UL |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 660 Ohms |
| Base Product Number | 9AS3D |
