Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CST |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 5 V |
| Voltage Range | 4 ~ 6V |
| Frequency | 2.73kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 5V, 10cm |
| Current – Supply | 80mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 70°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.354″ Dia (9.00mm) |
| Height – Seated (Max) | 0.197″ (5.00mm) |
| Base Product Number | CST-951 |
