Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CPT |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage Range | 1 ~ 20V |
| Frequency | 4kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 80dB @ 9V, 10cm |
| Current – Supply | 7mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.472″ Dia (12.00mm) |
| Height – Seated (Max) | 0.236″ (6.00mm) |
| Base Product Number | CPT-1255 |
