Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CPE |
| Packaging | Bag |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage – Rated | 10 V |
| Voltage Range | 50V (Max) |
| Frequency | – |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 97dB @ 10V, 10cm |
| Current – Supply | 11mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Panel Mount, Flange |
| Termination | Wire Leads |
| Size / Dimension | 1.181″ Dia (30.00mm) |
| Height – Seated (Max) | 0.220″ (5.60mm) |
| Base Product Number | CPE |
