Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CPE |
| Packaging | Box |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 12 V |
| Voltage Range | 6 ~ 14V |
| Frequency | 2.8kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 12V, 30cm |
| Current – Supply | 35mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | IP67 – Dust Tight, Waterproof |
| Mounting Type | Panel Mount, Flange |
| Termination | Wire Leads |
| Size / Dimension | 1.008″ Dia (25.60mm) |
| Height – Seated (Max) | 0.650″ (16.50mm) |
| Base Product Number | CPE |
Değerlendirmeler
Henüz değerlendirme yapılmadı.
