| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CMT |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 2 ~ 5V |
| Frequency | 4kHz |
| Technology | Magnetic |
| Operating Mode | – |
| Duration | – |
| Sound Pressure Level (SPL) | 75dB @ 3V, 10cm |
| Current – Supply | 100mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | – |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.197″ L x 0.197″ W (5.00mm x 5.00mm) |
| Height – Seated (Max) | 0.098″ (2.50mm) |
| Base Product Number | CMT-0502 |
