Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CMI |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 5 V |
| Voltage Range | 3 ~ 8V |
| Frequency | 2.7kHz |
| Technology | Magnetic |
| Operating Mode | – |
| Duration | – |
| Sound Pressure Level (SPL) | 80dB @ 5V, 10cm |
| Current – Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | – |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.382″ L x 0.382″ W (9.70mm x 9.70mm) |
| Height – Seated (Max) | 0.224″ (5.70mm) |
| Base Product Number | CMI-9705 |
