| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CEP |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 12 V |
| Voltage Range | 3 ~ 20V |
| Frequency | 3.4kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 78dB @ 12V, 30cm |
| Current – Supply | 15mA |
| Port Location | Top |
| Operating Temperature | -30°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.945″ Dia (24.00mm) |
| Height – Seated (Max) | 0.374″ (9.50mm) |
