Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Same Sky (Formerly CUI Devices) |
| Series | CEM |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3.5 V |
| Voltage Range | 3 ~ 5V |
| Frequency | 2.048kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 3.5V, 10cm |
| Current – Supply | 35mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 60°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.472″ Dia (12.00mm) |
| Height – Seated (Max) | 0.354″ (9.00mm) |
