Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | PUI Audio, Inc. |
| Series | SMTB |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 1 ~ 25V |
| Frequency | 4kHz |
| Technology | Piezo |
| Sound Pressure Level (SPL) | 75dB @ 3V, 10cm |
| Current – Supply | 3mA |
| Port Location | Side |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.472″ L x 0.472″ W (12.00mm x 12.00mm) |
| Height – Seated (Max) | 0.130″ (3.30mm) |
