Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | PUI Audio, Inc. |
| Series | SMTB |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 2 ~ 5V |
| Frequency | 2.7kHz |
| Technology | Electromechanical/Magnetic |
| Sound Pressure Level (SPL) | 95dB @ 3V, 10cm |
| Current – Supply | 80mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 105°C |
| Ratings | Washable |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.362″ Dia (9.20mm) |
| Height – Seated (Max) | 0.189″ (4.80mm) |
