Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | PUI Audio, Inc. |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 3.6 V |
| Voltage Range | 3 ~ 4.6V |
| Frequency | 2.83kHz |
| Technology | Electromechanical/Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 93dB @ 3.6V, 10cm |
| Current – Supply | 100mA |
| Port Location | Side |
| Operating Temperature | -20°C ~ 70°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.394″ L x 0.394″ W (10.00mm x 10.00mm) |
| Height – Seated (Max) | 0.138″ (3.50mm) |
