Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | PUI Audio, Inc. |
| Series | AT |
| Packaging | Tray |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Peak-Peak Signal |
| Voltage – Rated | 3 V |
| Voltage Range | 2 ~ 5V |
| Frequency | 2kHz |
| Technology | Electromechanical/Magnetic |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 85dB @ 3V, 10cm |
| Current – Supply | 80mA |
| Port Location | Top |
| Operating Temperature | -25°C ~ 70°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.472″ Dia (12.00mm) |
| Height – Seated (Max) | 0.177″ (4.50mm) |
