Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Pletronics, Inc |
| Series | UCE4 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 10 MHz |
| Function | Enable/Disable |
| Output | Clipped Sine Wave |
| Voltage – Supply | 3.3V |
| Frequency Stability | 0.5ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 3mA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | SMD 3.2mm x 2.5mm |
| Size / Dimension | 0.126″ L x 0.098″ W (3.20mm x 2.50mm) |
| Height – Seated (Max) | 0.035″ (0.90mm) |
| Current – Supply (Disable) (Max) | 0.23µA |
