Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Picker Components |
| Series | PTRA |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 220VAC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 40 A |
| Switching Voltage | 300VAC, 110VDC – Max |
| Load – Max Switching | 12000VA, 4400W |
| Coil Current | 163.1 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Quick Connect – 0.187″/0.250″ |
| Seal Rating | Sealed – Fully |
| Coil Insulation | Class F |
| Must Operate Voltage | 165 VAC |
| Must Release Voltage | 86 VAC |
| Operate Time | 15 ms |
| Release Time | 10 ms |
| Operating Temperature | -55°C ~ 100°C |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
| Approval Agency | CUL, cURus, UL |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 13.5 kOhms |
| Base Product Number | PTRA-1A |
