Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Picker Components |
| Series | – |
| Packaging | Tray |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Current | 110 mA |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Switching Voltage | 75VDC – Max |
| Must Operate Voltage | 7.2 VDC |
| Must Release Voltage | 1.2 VDC |
| Operate Time | 5 ms |
| Release Time | 2 ms |
| Features | Diode |
| Mounting Type | Socketable |
| Termination Style | Plug In |
| Operating Temperature | -40°C ~ 125°C |
| Contact Material | Silver Tin Oxide Indium Oxide (AgSnOInO) |
| Coil Power | 1.3W |
| Coil Resistance | 109 Ohms |
