Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Picker Components |
| Series | – |
| Packaging | Tube |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Current | 47.2 mA |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Switching Voltage | 28VDC – Max |
| Must Operate Voltage | 6.9 VDC |
| Must Release Voltage | 1.5 VDC |
| Operate Time | 4 ms |
| Release Time | 1.5 ms |
| Features | Sealed – Fully |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Operating Temperature | -40°C ~ 105°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Coil Power | 570mW |
| Coil Resistance | 254 Ohms |
