Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Phoenix Contact |
| Series | REL-MR |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 24VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 8 A |
| Switching Voltage | 250VAC, 250VDC – Max |
| Load – Max Switching | – |
| Coil Current | 32 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | PC Pin |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | – |
| Must Release Voltage | – |
| Operate Time | 12 ms |
| Release Time | 9 ms |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver Nickel (AgNi) |
| Approval Agency | cULus, EAC, UR |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 350 Ohms |
| Base Product Number | 29614 |
