| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Omron Electronics Inc-EMC Div |
| Series | G6B-4 |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | DIN Rail |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) x 4 |
| Contact Rating (Current) | 2 A |
| Switching Voltage | 380VAC, 125VDC – Max |
| Load – Max Switching | 760VA, 250W |
| Coil Current | 10.7 mA |
| Coil Type | Non Latching |
| Features | Diode, Lighted Indicator, Socket Included |
| Termination Style | Screw Terminal |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | 19.2 VDC |
| Must Release Voltage | 2.4 VDC |
| Operate Time | 10 ms |
| Release Time | 15 ms |
| Operating Temperature | -25°C ~ 55°C |
| Contact Material | – |
| Approval Agency | CE, CSA, UR, VDE |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 2.88 kOhms |
| Base Product Number | G6B-48 |
