Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Omron Electronics Inc-EMC Div |
| Series | G3VM |
| Packaging | Tube |
| Part Status | Last Time Buy |
| Mounting Type | Through Hole |
| Circuit | SPST-NC (1 Form B) |
| Output Type | AC, DC |
| Voltage – Input | 1.15VDC |
| Voltage – Load | 0 V ~ 350 V |
| Load Current | 150 mA |
| On-State Resistance (Max) | 25 Ohms |
| Termination Style | PC Pin |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 4-DIP (0.300″, 7.62mm) |
| Supplier Device Package | 4-DIP |
| Approval Agency | – |
| Grade | – |
| Qualification | – |
| Base Product Number | G3VM-35 |
