Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Ole Wolff Electronics Inc |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 5 V |
| Voltage Range | 1 ~ 6V |
| Frequency | 4kHz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Sound Pressure Level (SPL) | 100dB @ 5V, 10cm |
| Current – Supply | 150mA |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Termination | Solder Pads |
| Size / Dimension | 0.315″ L x 0.315″ W (8.00mm x 8.00mm) |
| Height – Seated (Max) | 0.157″ (4.00mm) |
