Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Murata Electronics |
| Series | PKHPS0013E40 |
| Packaging | Cut Tape (CT), Tape & Box (TB) |
| Part Status | Last Time Buy |
| Driver Circuitry | Transducer, Externally Driven |
| Input Type | Zero-Peak Signal |
| Voltage – Rated | 1.5 V |
| Voltage Range | 15V (Max) |
| Frequency | 4kHz |
| Technology | Piezo |
| Operating Mode | – |
| Duration | – |
| Sound Pressure Level (SPL) | 78dB @ 1.5V, 10cm |
| Current – Supply | – |
| Port Location | Top |
| Operating Temperature | -40°C ~ 85°C |
| Approval Agency | – |
| Ratings | – |
| Ingress Protection | – |
| Mounting Type | Through Hole |
| Termination | PC Pins |
| Size / Dimension | 0.496″ Dia (12.60mm) |
| Height – Seated (Max) | 0.390″ (9.90mm) |
