Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Microchip Technology |
| Series | DSC61XX |
| Packaging | Tube |
| Part Status | Obsolete |
| Base Resonator | MEMS |
| Type | XO (Standard) |
| Programmable Type | Blank (User Must Program) |
| Available Frequency Range | 1 MHz ~ 100 MHz |
| Function | Standby |
| Output | CMOS |
| Voltage – Supply | 1.71V ~ 3.63V |
| Frequency Stability | – |
| Frequency Stability (Total) | ±50ppm |
| Operating Temperature | -20°C ~ 70°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 3mA (Typ) |
| Ratings | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 4-VLGA |
| Supplier Device Package | 4-VLGA (2.5×2) |
| Size / Dimension | 0.098″ L x 0.079″ W (2.50mm x 2.00mm) |
| Height – Seated (Max) | 0.035″ (0.89mm) |
| Current – Supply (Disable) (Max) | 12 µA |
