Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Microchip Technology |
| Series | DSC61XXB |
| Packaging | Tube |
| Part Status | Active |
| Base Resonator | MEMS |
| Type | XO (Standard) |
| Programmable Type | – |
| Available Frequency Range | 3.5 kHz ~ 100 MHz |
| Function | Enable/Disable |
| Output | CMOS |
| Voltage – Supply | 1.8V ~ 3.3V |
| Frequency Stability | – |
| Frequency Stability (Total) | ±20ppm |
| Operating Temperature | -40°C ~ 125°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 3mA (Typ) |
| Ratings | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 4-VDFN |
| Supplier Device Package | 4-VDFN (5×3.2) |
| Size / Dimension | 0.197″ L x 0.126″ W (5.00mm x 3.20mm) |
| Height – Seated (Max) | 0.035″ (0.90mm) |
