Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Microchip Technology |
| Series | DSC60XXB |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Base Resonator | MEMS |
| Type | XO (Standard) |
| Programmable Type | Blank (User Must Program) |
| Available Frequency Range | 2 kHz ~ 80 MHz |
| Function | Enable/Disable |
| Output | CMOS |
| Voltage – Supply | 1.71V ~ 3.63V |
| Frequency Stability | – |
| Frequency Stability (Total) | ±20ppm |
| Operating Temperature | -40°C ~ 125°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 1.3mA (Typ) |
| Ratings | AEC-Q100 |
| Mounting Type | Surface Mount |
| Package / Case | 4-VFLGA |
| Supplier Device Package | 4-VFLGA (1.6×1.2) |
| Size / Dimension | 0.063″ L x 0.047″ W (1.60mm x 1.20mm) |
| Height – Seated (Max) | 0.035″ (0.89mm) |
| Base Product Number | DSC6003 |
