Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Mallory Sonalert Products Inc. |
| Series | PK |
| Packaging | Bulk |
| Part Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage – Rated | 12 V |
| Voltage Range | 3 ~ 28V |
| Frequency | 3.5kHz |
| Technology | Piezo |
| Operating Mode | Single Tone |
| Duration | – |
| Sound Pressure Level (SPL) | 90dB @ 12V, 30cm |
| Current – Supply | 15mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 70°C |
| Approval Agency | – |
| Ratings | – |
| Mounting Type | Panel Mount |
| Termination | Screw Terminal, Quick Connect Tab – 0.189″ (4.80mm) |
| Size / Dimension | 1.437″ Dia (36.50mm) |
| Height – Seated (Max) | 0.933″ (23.70mm) |
