Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Littelfuse Inc. |
| Series | – |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 200 A |
| Switching Voltage | 12VDC – Max |
| Coil Current | 685.7 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Stud |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | – |
| Must Release Voltage | – |
| Operating Temperature | -40°C ~ 85°C |
| Contact Material | Silver (Ag) |
| Relay Type | General Purpose |
| Coil Resistance | 17.5 Ohms |
| Base Product Number | 24213 |
