Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Littelfuse/Commercial Vehicle Products |
| Series | DCNLM |
| Packaging | Bulk |
| Part Status | Obsolete |
| Mounting Type | Chassis Mount |
| Coil Voltage | 48VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 50 A |
| Switching Voltage | 60VDC – Max |
| Features | – |
| Termination Style | Stud |
| Operating Temperature | -40°C ~ 70°C |
| Must Operate Voltage | 33.6 VDC |
| Must Release Voltage | 4 VDC |
| Contact Material | – |
| Operate Time | 40 ms |
| Release Time | 20 ms |
| Coil Power | – |
| Coil Resistance | – |
