| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Littelfuse/Commercial Vehicle Products |
| Series | DCNHR |
| Packaging | Bulk |
| Part Status | Obsolete |
| Mounting Type | Chassis Mount |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 30 A |
| Switching Voltage | 900VDC – Max |
| Features | – |
| Termination Style | Stud, Wire Leads |
| Operating Temperature | -40°C ~ 85°C |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2 VDC |
| Contact Material | – |
| Operate Time | 25 ms |
| Release Time | 12 ms |
| Coil Current | 145.8 mA |
| Coil Power | 3.5W |
| Coil Resistance | 164.57Ohms |
