Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | KYOCERA AVX |
| Series | FFB |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 47 µF |
| Tolerance | ±10% |
| Voltage Rating – AC | 45V |
| Voltage Rating – DC | 75V |
| Dielectric Material | Polyester, Metallized |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.224″ L x 0.575″ W (31.10mm x 14.60mm) |
| Height – Seated (Max) | 1.012″ (25.70mm) |
| Termination | PC Pins |
| Lead Spacing | 1.083″ (27.50mm) |
| Applications | DC Link, DC Filtering |
| Ratings | – |
| Features | – |
