Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | KYOCERA AVX |
| Series | CX2016SA, Kyocera |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | MHz Crystal |
| Frequency | 24 MHz |
| Frequency Stability | ±35ppm |
| Frequency Tolerance | ±30ppm |
| Load Capacitance | 6pF |
| ESR (Equivalent Series Resistance) | 120 Ohms |
| Operating Mode | Fundamental |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | AEC-Q200 |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.079″ L x 0.063″ W (2.00mm x 1.60mm) |
| Height – Seated (Max) | 0.020″ (0.50mm) |
