Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | KEMET |
| Series | PHE845 |
| Packaging | Tray |
| Part Status | Active |
| Capacitance | 0.1 µF |
| Tolerance | ±20% |
| Voltage Rating – AC | 760V |
| Voltage Rating – DC | 1500V (1.5kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -40°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.024″ L x 0.433″ W (26.00mm x 11.00mm) |
| Height – Seated (Max) | 0.846″ (21.50mm) |
| Termination | PC Pins |
| Lead Spacing | 0.886″ (22.50mm) |
| Applications | EMI, RFI Suppression |
| Ratings | X1 |
| Features | – |
| Base Product Number | PHE845 |
