Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | KEMET |
| Series | PHE426 |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 1 µF |
| Tolerance | ±5% |
| Voltage Rating – AC | 160V |
| Voltage Rating – DC | 250V |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.709″ L x 0.374″ W (18.00mm x 9.50mm) |
| Height – Seated (Max) | 0.689″ (17.50mm) |
| Termination | PC Pins |
| Lead Spacing | 0.591″ (15.00mm) |
| Applications | DC Link, DC Filtering; High Frequency, Switching; High Pulse, DV/DT |
| Ratings | – |
| Features | – |
| Base Product Number | PHE426 |
