Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | KEMET |
| Series | C4BT |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 20 µF |
| Tolerance | ±5% |
| Voltage Rating – AC | 330V |
| Voltage Rating – DC | 600V |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 1.7 mOhms |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
| Size / Dimension | 2.264″ L x 1.378″ W (57.50mm x 35.00mm) |
| Height – Seated (Max) | 1.969″ (50.00mm) |
| Termination | Screw Terminals |
| Lead Spacing | 1.614″ (41.00mm) |
| Applications | DC Link, DC Filtering; High Frequency, Switching |
| Ratings | – |
| Features | – |
| Base Product Number | C4BTHB |
