Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | KEMET |
| Series | C4BS |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 1 µF |
| Tolerance | ±5% |
| Voltage Rating – AC | 630V |
| Voltage Rating – DC | 1200V (1.2kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 3.3 mOhms |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Chassis Mount |
| Package / Case | Rectangular Box |
| Size / Dimension | 1.673″ L x 1.102″ W (42.50mm x 28.00mm) |
| Height – Seated (Max) | 1.457″ (37.00mm) |
| Termination | Screw Terminals |
| Lead Spacing | 1.004″ (25.50mm) |
| Applications | DC Link, DC Filtering; Snubber |
| Ratings | – |
| Features | – |
| Base Product Number | C4BSPB |
