Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | KEMET |
| Series | C276 |
| Packaging | Box |
| Part Status | Active |
| Capacitance | 2.5µF |
| Tolerance | ±5% |
| Voltage Rating – AC | 470V |
| Voltage Rating – DC | – |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -25°C ~ 85°C |
| Polarization | – |
| Applications | Motor Run |
| Lead Spacing | 0.394″ (10.00mm) |
| Size / Dimension | 0.984″ Dia (25.00mm) |
| Height – Seated (Max) | 2.362″ (60.00mm) |
| Mounting Type | Chassis, Stud Mount |
| Package / Case | Radial, Can |
| Base Product Number | C276CC |
