Açıklama

ÖZELLİK	AÇIKLAMA
Manufacturer	KEMET
Series	APL9V
Packaging	Tray
Part Status	Active
Type	Polymer
Capacitance	60 µF
Tolerance	±20%
Voltage – Rated	250 V
ESR (Equivalent Series Resistance)	25.5mOhm
Lifetime @ Temp.	2000 Hrs @ 125°C
Operating Temperature	-40°C ~ 125°C
Ratings	AEC-Q200
Applications	Automotive
Features	–
Ripple Current @ High Frequency	12.44 A @ 100 kHz
Lead Spacing	0.500″ (12.70mm)
Size / Dimension	2.118″ L x 1.024″ W (53.80mm x 26.00mm)
Height – Seated (Max)	0.394″ (10.00mm)
Surface Mount Land Size	–
Mounting Type	Through Hole
Package / Case	FlatPack
