Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Jauch Quartz |
| Series | JTX210 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | kHz Crystal (Tuning Fork) |
| Frequency | 32.768 kHz |
| Frequency Stability | – |
| Frequency Tolerance | ±20ppm |
| Load Capacitance | 6pF |
| ESR (Equivalent Series Resistance) | 90 kOhms |
| Operating Mode | Fundamental |
| Operating Temperature | -40°C ~ 125°C |
| Ratings | AEC-Q200 |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD, No Lead |
| Size / Dimension | 0.079″ L x 0.047″ W (2.00mm x 1.20mm) |
| Height – Seated (Max) | 0.024″ (0.60mm) |
