| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | IDEC |
| Series | RY |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | Socketable |
| Coil Voltage | 24VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 3 A |
| Switching Voltage | 240VAC, 30VDC – Max |
| Load – Max Switching | 720VA, 90W |
| Coil Current | 37 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | Plug In |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | 19.2 VAC |
| Must Release Voltage | 7.2 VAC |
| Operate Time | 20 ms |
| Release Time | 20 ms |
| Operating Temperature | -25°C ~ 55°C |
| Contact Material | Silver (Ag), Gold (Au) |
| Approval Agency | CE, CSA, TUV, UR |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 300 Ohms |
| Base Product Number | RY2S-U |
