Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | IDEC |
| Series | RV8 |
| Packaging | Bulk |
| Part Status | Active |
| Mounting Type | DIN Rail |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 6 A |
| Switching Voltage | 400VAC, 125VDC – Max |
| Load – Max Switching | 2400VA, 750W |
| Coil Current | 14.6 mA |
| Coil Type | Non Latching |
| Features | Socket Included |
| Termination Style | Screw Terminal |
| Seal Rating | – |
| Coil Insulation | – |
| Must Operate Voltage | 10.8 VDC |
| Must Release Voltage | 0.84 VDC |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver Nickel (AgNi), Gold (Au) |
| Approval Agency | CE, cULus |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 821.9 Ohms |
| Base Product Number | RV8H-L |
