Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Golledge Electronics Ltd |
| Series | GTXO-94 |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 32.768 kHz |
| Function | Enable/Disable |
| Output | CMOS |
| Voltage – Supply | 3.3V |
| Frequency Stability | ±5ppm |
| Absolute Pull Range (APR) | – |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | – |
| Current – Supply (Max) | 2µA |
| Ratings | – |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.129″ L x 0.102″ W (3.28mm x 2.58mm) |
| Height – Seated (Max) | 0.058″ (1.47mm) |
| Current – Supply (Disable) (Max) | – |
