Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Ezurio |
| Series | i.MX 8M |
| Packaging | Tray |
| Part Status | Active |
| Core Processor | ARM® Cortex®-A53, ARM® Cortex®-M7 |
| Speed | 800MHz, 1.8GHz |
| Number of Cores | 5 |
| Size / Dimension | 3.228″ L x 1.969″ W (82.00mm x 50.00mm) |
| Form Factor | SMARC v2.1.1 |
| RAM Capacity/Installed | 4GB/4GB |
| Storage Interface | eMMC Flash, LPDDR4 |
| Video Outputs | HDMI, LVDS, MIPI DSI |
| USB | USB 2.0 (1), USB 2.0 OTG (1), USB 3.0 (2) |
| Watchdog Timer | – |
| Operating Temperature | 0°C ~ 70°C |
